When a diesel misfires, idles rough, knocks or smokes right after new injectors go in, the cause is usually something about the installation, not a defective injector. Check the ten items below before pulling the new injectors back out. Several of them can be confirmed without removing anything.
1. Injector coding
On engines that use trim or correction codes, each new or remanufactured injector’s code must be programmed to the correct cylinder. A missing code, an old code left in memory or codes entered to the wrong cylinders will make the engine run unevenly. Check this first. See diesel injector coding.
2. Air in the fuel system
Fuel lines and filters were opened. If the system wasn’t bled completely, air causes rough running, misfire and stalling until it clears, and sometimes it doesn’t clear on its own. Bleed the system following the engine maker’s procedure. See air in the diesel fuel system.
3. Sealing washers
Many injectors seal against the cylinder head with a copper washer. A classic mistake is leaving the old washer stuck in the bore and installing a new one on top. A doubled washer raises the injector, changes its spray position and can cause misfire, smoke and combustion leaks. A missing washer is just as bad. Check that each bore had its old washer removed and exactly one new one installed. A seal that leaks combustion gas after installation leads to the carbon buildup described in injector seal leaks and “black death”.
4. O-rings and seals
Pinched, rolled or reused O-rings cause leaks. On HEUI engines, a damaged O-ring can leak high-pressure oil and lower injection control pressure, or let fuel into the oil. On other engines, it can allow fuel or air leaks.
5. High-pressure connections
On engines like the 5.9 and 6.7 Cummins common rail, the high-pressure connector tube should be replaced with each injector, and the tightening sequence matters. A reused or incorrectly tightened connector leaks internally, lowering rail pressure. On all common-rail engines, high-pressure lines must be tightened to specification. See 6.7 Cummins injector problems.
6. Hold-down clamps and torque
Injector hold-downs must be installed and tightened in the specified sequence. An injector that isn’t seated squarely may leak, misfire or be damaged. Some engines specify single-use hold-down bolts.
7. Electrical connections
Connectors that aren’t fully seated, terminals damaged during installation, and harnesses pinched under covers cause misfires and injector circuit codes. Check each connection.
8. Correct part numbers
Confirm every injector is the correct part number for the engine and, where it matters, for the cylinder position. Some engines use a different injector in one position; the 7.3 Power Stroke’s cylinder 8 is a well-known example. Mixed injectors from different sources or calibrations can also cause imbalance.
9. Debris introduced during installation
Dirt that entered open lines, rails or injector bores during the job can lodge in a new injector. Symptoms may be immediate or develop over the first few hundred miles. Clean work practices and capped openings prevent it.
10. The original problem
If the old injectors failed because of low supply pressure, air in the fuel, water, a failing pump, low compression, wiring problems or low injector driver voltage, the new injectors face the same conditions. A misfire after replacement may simply be the original problem, still there. Recheck supply pressure, wiring, compression and, on HEUI engines, oil condition and driver voltage.
A note on learned values
Some engines store learned corrections for each cylinder. After injector replacement, the engine maker may call for resetting those values or running a relearn procedure. Leftover corrections from the old injectors can make new ones look bad.
Further technical reference: Bosch Mobility: common-rail system overview. Use the exact engine/injector/pump service information for applicable procedures and limits.
